Nissan Rogue II facelift (2016-2020) open sw Wiring diagram
This page shows the only wiring diagram for the component.open sw, which is found in the car Nissan Rogue II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open sw (1 of 1)
AUT UNLK REG
AUTOMATIC BACK DOOR CLOSE SWITCH
AUTOMATIC BACK DOOR CONTROL MODULE
AUTOMATIC BACK DOOR SWITCH
B+1
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN L
CAN-H
CLOSE SW
COMPUTER DATA LINES SYSTEM
DRIVER SW
EXCEPT HYBRID
FUSE 52
FUSE 75
FUSE, FUSIBLE LINK BOX
FUSE, FUSIBLE LINK, RELAY BOX 1
GRN WIRE
GRY WIRE
HALF LATCH SW
HOT AT ALL TIMES
INSIDE CLOSE SW
IR SENS DUMMY SIG
KICK SENS PWR
KICK SENS SIG
LATCH MTR CLOSE
LATCH MTR OPEN
LEFT SPINDLE UNIT
LEFT TOUCH SENSOR
LH A SIGN
LH B SIGN
LH POWER
LH TOUCH SENS
LT BLU WIRE
LT GRN WIRE
OPEN SW
P B/D LH MTR CLOSE
P B/D LH MTR OPEN
P B/D RH MTR CLOSE
P B/D RH MTR OPEN
PNK WIRE
POWER GND
PPL
PPL/BLU WIRE
RED WIRE
RH A SIGN
RH B SIGN
RH POWER
RH TOUCH SENS
RIGHT TOUCH SENSOR
SHIELD
SPINDLE MOTOR
SPINDLE NOISE
TAN WIRE
TOUCH SENS GND
WHT WIRE
YEL WIRE
Go to component -> Back door opener circuit, w/ automatic back door system (1 of 2) -> OPEN SW
