Nissan Rogue II facelift (2016-2020) lh mir select sw Wiring diagrams

This page contains all the electrical diagrams for the component. lh mir select sw, in which he is found in the car Nissan Rogue II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

lh mir select sw wiring diagram (1 of 2)

Nissan Rogue II facelift (2016-2020) lh mir select sw wiring diagram (1 of 2)

AUTOMATIC DRIVE POSITIONER CONTROL UNIT BACKWARD BAT (PTC) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE BWD FWD CAN L CAN-H CIRCUIT BREAKER 2 COMPUTER DATA LINES SYSTEM FORWARD/ FUSE 14 FUSE 6 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX 1 FUSIBLE LINK N GND PWR GND SENS GND GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR SWITCH LH COM MIR MTR LH HORIZ MIR MTR LH HORIZ MIR SENS LH MIR SELECT SW LH VERT MIR MTR LH VERT MIR SENS LT BLU WIRE LT GRN WIRE LUMBAR SUPPORT MOTOR LUMBAR SUPPORT SWITCH MIR SW (DOWNWARD) MIR SW (LEFTWARD) MIR SW (RIGHTWARD) MIR SW (UPWARD) PPL PPL/BLK WIRE PPL/GRY WIRE RED WIRE RH COM MIR MTR RH HORIZ MIR MTR RH HORIZ MIR SENS RH MIR SELECTOR SW RH VERT MIR MTR RH VERT MIR SENS SHORTING PIN TAN WIRE UART (TX/RX) WHT WIRE YEL WIRE

Go to component -> Memory systems circuit, except hybrid (1 of 3) -> LH MIR SELECT SW

lh mir select sw wiring diagram (2 of 2)

Nissan Rogue II facelift (2016-2020) lh mir select sw wiring diagram (2 of 2)

AUTOMATIC DRIVE POSITIONER CONTROL UNIT BACKWARD BAT (PTC) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE BWD FWD CAN L CAN-H CIRCUIT BREAKER 2 COMPUTER DATA LINES SYSTEM FORWARD/ FUSE 14 FUSE 6 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX 1 FUSIBLE LINK N GND 2 GND PWR GND SENS GND GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DOOR SWITCH LH COM MIR MTR LH HORIZ MIR MTR LH HORIZ MIR SENS LH MIR SELECT SW LH VERT MIR MTR LH VERT MIR SENS LT BLU WIRE LT GRN WIRE LUMBAR SUPPORT MOTOR LUMBAR SUPPORT SWITCH MIR SW (DOWNWARD) MIR SW (LEFTWARD) MIR SW (RIGHTWARD) MIR SW (UPWARD) PPL PPL/GRY WIRE RED WIRE RH COM MIR MTR RH HORIZ MIR MTR RH HORIZ MIR SENS RH MIR SELECTOR SW RH VERT MIR MTR RH VERT MIR SENS SHORTING PIN TAN WIRE UART (TX/RX) WHT WIRE YEL WIRE

Go to component -> Memory systems circuit, hybrid (1 of 3) -> LH MIR SELECT SW
