Nissan Rogue II facelift (2016-2020) lh com mir mtr Wiring diagrams
This page contains all the electrical diagrams for the component. lh com mir mtr, in which he is found in the car Nissan Rogue II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lh com mir mtr (1 of 2)
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
BACKWARD
BAT (PTC)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
BWD FWD
CAN L
CAN-H
CIRCUIT BREAKER 2
COMPUTER DATA LINES SYSTEM
FORWARD/
FUSE 14
FUSE 6
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK N
GND PWR
GND SENS GND
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SWITCH
LH COM MIR MTR
LH HORIZ MIR MTR
LH HORIZ MIR SENS
LH MIR SELECT SW
LH VERT MIR MTR
LH VERT MIR SENS
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
MIR SW (DOWNWARD)
MIR SW (LEFTWARD)
MIR SW (RIGHTWARD)
MIR SW (UPWARD)
PPL
PPL/BLK WIRE
PPL/GRY WIRE
RED WIRE
RH COM MIR MTR
RH HORIZ MIR MTR
RH HORIZ MIR SENS
RH MIR SELECTOR SW
RH VERT MIR MTR
RH VERT MIR SENS
SHORTING PIN
TAN WIRE
UART (TX/RX)
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit, except hybrid (1 of 3) -> LH COM MIR MTR
