Nissan Rogue II facelift (2016-2020) left license plate lamp, right license plate lamp, left backup lamp assembly, Wiring diagram
This page shows the only wiring diagram for the component.left license plate lamp, right license plate lamp, left backup lamp assembly,, which is found in the car Nissan Rogue II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left license plate lamp, right license plate lamp, left backup lamp assembly, (1 of 1)
AUTOMATIC BACK DOOR CLOSE SWITCH (IF EQUIPPED),
AUTOMATIC BACK DOOR CONTROL MODULE (IF EQUIPPED),
AUTOMATIC BACK DOOR WARNING BUZZER
AWD CONTROL UNIT (IF EQUIPPED), LEFT REAR COMBINATION LAMP,
BACK DOOR LOCK ASSEMBLY
BACK DOOR OPENER SWITCH (W/ AUTOMATIC BACK DOOR),
BLK WIRE
BOSE SPEAKER AMP
HORN (LOW), HPCM,
LEFT LICENSE PLATE LAMP, RIGHT LICENSE PLATE LAMP, LEFT BACKUP LAMP ASSEMBLY,
LEFT REAR LIFTING MOTOR
LI-ION BATTERY
MOTION ACTIVATED BACK DOOR CONTROL UNIT
RIGHT BACKUP LAMP ASSEMBLY, REAR WINDOW DEFOGGER
RIGHT SIDE RADAR (W/ DRIVER ASSISTANCE SYSTEM),
TCU
Go to component -> Ground distribution circuit, hybrid (1 of 2) -> LEFT LICENSE PLATE LAMP, RIGHT LICENSE PLATE LAMP, LEFT BACKUP LAMP ASSEMBLY,
