Nissan Rogue II facelift (2016-2020) left backup lamp assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left backup lamp assembly, in which he is found in the car Nissan Rogue II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left backup lamp assembly (1 of 2)
Go to component -> Backup lamps circuit -> LEFT BACKUP LAMP ASSEMBLY
Wiring diagram left backup lamp assembly (2 of 2)
BEHIND LEFT QUARTERPANEL)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR
ECM (ENGINE CONTROL MODULE)
EXCEPT HYBRID
FUSE 10
FUSE 30
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ IGNITION RELAY-2 ENERGIZED
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LED DAYTIME, PARKING LAMP CONTROL MODULE
LEFT BACKUP LAMP ASSEMBLY
LEFT FRONT COMBINATION LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LT GRN WIRE
PNK WIRE
PPL
PPL ST LP SW
PPL/BRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
RIGHT BACKUP LAMP ASSEMBLY
RIGHT FRONT COMBINATION LAMP
RIGHT LICENSE PLATE LAMP
SHIFT LOCK RELAY
SIDE MARKER
SMART FET
STOP
STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
TAIL
TAN WIRE
TURN SIGNAL
W/ HALOGEN HEADLAMP
W/ INTELLIGENT KEY SYSTEM
W/O INTELLIGENT KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> LEFT BACKUP LAMP ASSEMBLY
