Nissan Rogue II facelift (2016-2020) hi volt cooling water temp sens sensor gnd Wiring diagram
This page shows the only wiring diagram for the component.hi volt cooling water temp sens sensor gnd, which is found in the car Nissan Rogue II facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi volt cooling water temp sens sensor gnd (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONNECTION DETECTING CKT
ELECTRIC WATER PMP
ELECTRIC WATER PUMP (UPPER REAR OF ENGINE)
FUSE 69
FUSE 70
FUSE 71
FUSE 72
FUSE 73
FUSE 74
FUSIBLE LINK Y
GRY WIRE
HI VOLT COOLING WATER TEMP SENS SENSOR GND
HIGH VOLTAGE COOLANT TEMPERATURE SENSOR
HIGH VOLTAGE FUSE, FUSIBLE LINK, RELAY BOX
HOT AT ALL TIMES
HPCM (LEFT SIDE OF DASH)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PRE-CHARGE SIG
RED WIRE
SELF SHUT OFF RELAY
SELF SHUT OFF RLY
SERVICE PLUG
SYSTEM MAIN RLY 1
SYSTEM MAIN RLY 2
TAN WIRE
WATER PMP (FEED BACK)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l hybrid, hybrid system circuit (1 of 5) -> HI VOLT COOLING WATER TEMP SENS SENSOR GND
