Nissan Rogue II facelift (2016-2020) display forward Wiring diagrams
This page contains all the electrical diagrams for the component. display forward, in which he is found in the car Nissan Rogue II facelift (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
display forward wiring diagram (1 of 2)
ANT B+
ANT MAIN
ANTENNA AMP
ANTENNA BASE
AV CONTROL UNIT (W/ NAVIGATION) AUDIO UNIT (W/O NAVIGATION)
BACK
BLK WIRE
BLU WIRE
BRN WIRE
DISPLAY BACK
DISPLAY FORWARD
FR SP LH (-)
FR SP RH (-)
GPS ANT
GPS ANT SHIELD
GRN WIRE
GRY WIRE
IGN
LT GRN WIRE
MAIN GND
MENU DOWN
MENU OK
MENU UP
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL/GRN WIRE
PPL/RED WIRE
RED WIRE
REVERSE SIG
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER
RR SP LH (-)
RR SP RH (-)
SAT ANT
SAT ANT SHIELD
SATELLITE ANTENNA
SEEK DOWN
SEEK UP
SHIELD
STEERING SWITCHES
TEL END
TEL/VR
V-BUS
VOLUME DOWN
VOLUME UP
W/ 4 SPEAKERS
W/ 6 SPEAKERS
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, w/o bose (3 of 3) -> DISPLAY FORWARD
display forward wiring diagram (2 of 2)
ANT B+
ANT MAIN
ANTENNA AMP
ANTENNA BASE
AV CONTROL UNIT (W/ NAVIGATION) AUDIO UNIT (W/O NAVIGATION)
BACK
BLK WIRE
BLU WIRE
BRN WIRE
DISPLAY BACK
DISPLAY FORWARD
FR SP LH (-)
FR SP RH (-)
GPS ANT
GPS ANT SHIELD
GRN WIRE
GRY WIRE
IGN
LT GRN WIRE
MAIN GND
MENU DOWN
MENU OK
MENU UP
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL/GRN WIRE
PPL/RED WIRE
RED WIRE
REVERSE SIG
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER
RR SP LH (-)
RR SP RH (-)
SAT ANT
SAT ANT SHIELD
SATELLITE ANTENNA
SEEK DOWN
SEEK UP
SHIELD
STEERING SWITCHES
TEL END
TEL/VR
V-BUS
VOLUME DOWN
VOLUME UP
W/ 4 SPEAKERS
W/ 6 SPEAKERS
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, w/o bose (3 of 3) -> DISPLAY FORWARD
