Nissan Rogue II (2013-2016) w/ halogen headlamp w/ led headlamp Wiring diagram
This page shows the only wiring diagram for the component.w/ halogen headlamp w/ led headlamp, which is found in the car Nissan Rogue II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ halogen headlamp w/ led headlamp (1 of 1)
ASSEMBLY
BACK-UP LAMP ASSEMBLY LH
BACK-UP LAMP ASSEMBLY RH
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISTRIBUTION
ENGINE COMPT)
ENGINE ROOM
FRONT COMBINATION LAMP LH
FRONT COMBINATION LAMP RH
FUSE 10
FUSE BLOCK (J/B) (LEFT END OF DASH)
GRY WIRE
HEADLIGHT
HOT AT ALL TIMES
HOT IN ON OR START
INTELLIGENT
LED DAYTIME, PARKING LAMP CONTROL MODULE
LICENSE PLATE LAMP LH
LICENSE PLATE LAMP RH
LT GRN WIRE
MODULE
OF DASH)
PANEL)
PILLAR)
PNK WIRE
POWER
PPL/BRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
QUARTER
RED WIRE
RR COMBINATION LAMP LH
SIDE MARKER
SMART FET
STOP
STOP LAMP SWITCH
TAIL
TAN WIRE
TURN SIGNAL
VIO WIRE
W/ HALOGEN HEADLAMP W/ LED HEADLAMP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> W/ HALOGEN HEADLAMP W/ LED HEADLAMP
