Nissan Rogue II (2013-2016) power lh power rh gnd driver sw inside close sw can-h pnk Wiring diagram

1 3 SHIELD SHIELD 25 26 27 28 29 30 31 32 33 34 35 36 37 38 BATTERY AUTOMATIC BACK DOOR CLOSE SWITCH (BOTTOM LEFT OF BACK DOOR) AUTOMATIC BACK DOOR CONTROL MODULE (BEHIND LEFT REAR QUARTER PANEL) AUTOMATIC BACK DOOR MAIN SWITCH AUTOMATIC BACK DOOR SWITCH AUTOMATIC BACK DOOR WARNING BUZZER (BEHIND LEFT END OF REAR BUMPER) BACK DOOR LOCK ASSEMBLY (BOTTOM CENTER OF BACK DOOR) BACK DOOR OPENER SWITCH BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CINCH LATCH MOTOR CIRCUIT BREAKER-1 (LOWER CENTER OF DASH) CLOSE SWITCH DOOR AJAR SWITCH DOOR BUTTON FUSE FUSE 7 FUSE BLOCK (J/B) (LEFT END FUSE 5 OF DASH) GRN WIRE GRY WIRE HALF SWITCH HOT AT ALL TIMES HZD LMP OFF REQ I PWR I PWR ECU I SES BACK I SHORTING I TGATE SW I TGATE LATCH MTR OPEN POWER GND LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE OPEN OPEN OPEN SWITCH OPENER SW OTHER CLOSED P B/D LH MTR CLOSE SPINDLE NOISE P B/D RH MTR CLOSE BUZZER LATCH MTR CLOSE P B/D LH MTR OPEN P B/D RH MTR OPEN PIN PNK COMPUTER DATA LINES SYSTEM WIRE PNK SHIELD WIRE PNK WIRE POWER LH POWER RH GND DRIVER SW INSIDE CLOSE SW CAN-H PNK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT GRN WIRE PPL/VIO WIRE PPL/WHT WIRE RED WIRE RIGHT END OF DASH) SHIELD SPINDLE UNIT LH (TOP OF LEFT "D" PILLAR) SPINDLE UNIT RH (TOP OF RIGHT "D" PILLAR) TAN WIRE TOUCH SENSOR RH (RIGHT OUTER EDGE OF BACK DOOR) VIO WIRE WHT WIRE YEL WIRE
