Nissan Rogue II (2013-2016) passenger side front power window switch Wiring diagram
This page shows the only wiring diagram for the component.passenger side front power window switch, which is found in the car Nissan Rogue II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side front power window switch (1 of 1)
& N
1 2 PNK WIRE
B+ B-
BETWEEN FULL STROKE,
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN-H GND CAN-L
COMBINATION METER
CONSOLE INSIDE KEY ANTENNA (UNDER CENTER CONSOLE)
CVT SHIFT SELECTOR
DOOR LOCK ACTUATOR
DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR)
DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR)
DOOR LOCK ASSEMBLY (REAR OF DRIVER'S DOOR)
DOOR LOCK, UNLOCK SWITCH
DRIVER SIDE FRONT
FULL STROKE BETWEEN
FUSE
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GRN WIRE
HOT AT ALL TIMES
IND
KEY
KEY (GREEN) IND
KEY (LOCK) IND
LEFT REAR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK POSITION SWITCH
PASSENGER SIDE FRONT POWER WINDOW SWITCH
PNK WIRE
POWER WINDOW MAIN SWITCH
PPL
PPL 3 4 5 6 7
REAR BUMPER OUTSIDE KEY ANTENNA
REAR SEAT INSIDE KEY ANTENNA (UNDER LEFT SIDE OF REAR SEAT)
RED WIRE
RIGHT REAR
STROKE FULL
SWITCH LOCK
UNIFIED METER CONTROL UNIT
UNLOCK SENSOR
UNLOCK SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit, with intelligent key unit (2 of 3) -> PASSENGER SIDE FRONT POWER WINDOW SWITCH
