Nissan Rogue II (2013-2016) m can-h Wiring diagrams
This page contains all the electrical diagrams for the component. m can-h, in which he is found in the car Nissan Rogue II (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram m can-h (1 of 5)
24 25 PNK PNK WIRE
BLU WIRE
BUZZER
CAN L
CAN-H
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
DASH)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DISPLAY
FUSE 30
FUSE 7
FUSE FUSE 14
FUSE, FUSIBLE LINK, FUSE 33 RELAY BOX (LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I PWR ECU
I SHORTING PIN
J/C
LIGHT SENSOR (-)
LT BLU WIRE
LT GRN WIRE
M CAN-H
M CAN-L
MENU MENU SOURCE UP UP
MENU VR DOWN
O GND AUTO-
PNK WIRE
RED WIRE
STEERING SWITCHES
STG SW GND
TAN WIRE
UNIFIED METER CONTROL UNIT WITH INFORMATION DISPLAY
VIO WIRE
VOLUME ENTER DOWN
VOLUME TEL BACK OFF UP
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, base (2 of 3) -> M CAN-H
