Nissan Rogue II (2013-2016) i tgate opener sw 51 53 50 57 52 i tgate sw Wiring diagram

1 15 LOCK 1 2 W/ POWER BACK DOOR W/O POWER BACK DOOR 104 93 I DR KNOB SW PNK I KEY CYLINDER UNLOCK SW WIRE ACTUATOR BACK DOOR OPENER SWITCH BCM (BODY BLK WIRE BLU WIRE BRN WIRE BUZZER CAN L CAN-H COMBINATION METER CONTROL MODULE DOOR BACK DOOR LOCK ASSEMBLY (BOTTOM CENTER OF BACK DOOR) AJAR SWITCH DOOR KNOB FRONT DOOR LOCK ACTUATOR RH FRONT DOOR SWITCH LH (LEFT "B" PILLAR) FRONT DOOR) FRONT REAR DOOR DOOR SWITCH RH SWITCH RH (RIGHT (RIGHT "B" PILLAR) "C" PILLAR) FULL FUSE FUSE 31 (LEFT END OF DASH) FUSE BLOCK (J/B) GND 2 GND UNLOCK GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I DOOR LOCK SW I DOOR UNLOCK SW I RL DOOR SW I RR DOOR SW I SES BACKDOOR BUTTON SW I TGATE OPENER SW 51 53 50 57 52 I TGATE SW I-KEY CYLINDER LOCK SW LOCK LOCK ASSEMBLY LH LT BLU WIRE LT GRN WIRE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH O AS LOCK OR UNLOCK D O DR OR FR LOCK D O FR OR DR UNLOCK D OF DASH) PNK WIRE POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/VIO WIRE REAR DOOR) RED WIRE RIGHT END OF DASH) SENSOR STROKE SWITCH SWITCH LH (LEFT "C" PILLAR) TAN WIRE UNIFIED METER CONTROL UNIT UNLOCK VIO WIRE WHT WIRE YEL WIRE
