Nissan Rogue II (2013-2016) fuse 61 fuse 62 Wiring diagram
This page shows the only wiring diagram for the component.fuse 61 fuse 62, which is found in the car Nissan Rogue II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 61 fuse 62 (1 of 1)
BLK WIRE
BLU WIRE
FRONT FOG LAMP RELAY
FUSE 43
FUSE 44 FUSE 49
FUSE 50
FUSE 61 FUSE 62
FUSE 65
FUSIBLE LINK C
GRN WIRE
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HOT AT ALL TIMES
HOT AT ALL TIMES FUSIBLE LINK HOLDER
HOT IN ON OR START
IGNITION RELAY
LEFT FRONT FOG LAMP
LEFT HIGH HEADLAMP
LEFT LOW HEADLAMP
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HIGH HEADLAMP
RIGHT LOW HEADLAMP
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, with drl (2 of 2) -> FUSE 61 FUSE 62
