Nissan Rogue II (2013-2016) front tweeter rh Wiring diagrams
This page contains all the electrical diagrams for the component. front tweeter rh, in which he is found in the car Nissan Rogue II (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
front tweeter rh wiring diagram (1 of 2)
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 AUX R AUX GND AUX L
8 9 CAN H ILL (+) LIGHT SW
AUX IN JACK
AV CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAN L SPEED SIGNAL BATTERY GND
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM
FR SP LH (+) FR SP LH (-) RR SP LH (+) RR SP LH (-) PNK WIRE
FR SP RH (+) FR SP RH (-) RR SP RH (+) RR SP RH (-)
FRONT DOOR SPEAKER LH
FRONT DOOR SPEAKER RH
FRONT TWEETER LH
FRONT TWEETER RH
FUSE 50
GRN WIRE
GRY WIRE
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MCAN+ MCAN- IGNITION
MIC SIG MIC VCC SHIELD MIC GND SUB OUT/AUX SHIELD SHIELD
MICROPHONE (IN ROOF CONSOLE)
MR OUTPUT M-CAN TERMINATION M-CAN TERMINATION
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/YEL WIRE
REAR DOOR SPEAKER LH
RED WIRE
REVERSE
SHIELD
SHIELD SHIELD
TAN WIRE
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF TRANSMISSION)
USB GND USB SHIELD SHIELD
USB INTERFACE
V BUS USB D- USB D+
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, base (1 of 3) -> FRONT TWEETER RH
front tweeter rh wiring diagram (2 of 2)
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 AUX R AUX GND AUX L
8 9 CAN H ILL (+) LIGHT SW
AUX IN JACK
AV CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAN L SPEED SIGNAL BATTERY GND
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM
FR SP LH (+) FR SP LH (-) RR SP LH (+) RR SP LH (-) PNK WIRE
FR SP RH (+) FR SP RH (-) RR SP RH (+) RR SP RH (-)
FRONT DOOR SPEAKER LH
FRONT DOOR SPEAKER RH
FRONT TWEETER LH
FRONT TWEETER RH
FUSE 50
GRN WIRE
GRY WIRE
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MCAN+ MCAN- IGNITION
MIC SIG MIC VCC SHIELD MIC GND SUB OUT/AUX SHIELD SHIELD
MICROPHONE (IN ROOF CONSOLE)
MR OUTPUT M-CAN TERMINATION M-CAN TERMINATION
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/YEL WIRE
REAR DOOR SPEAKER LH
RED WIRE
REVERSE
SHIELD
SHIELD SHIELD
TAN WIRE
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF TRANSMISSION)
USB GND USB SHIELD SHIELD
USB INTERFACE
V BUS USB D- USB D+
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, base with navigation (1 of 3) -> FRONT TWEETER RH
