Nissan Rogue II (2013-2016) exterior lights system air conditioning, defogger systems Wiring diagram
This page shows the only wiring diagram for the component.exterior lights system air conditioning, defogger systems, which is found in the car Nissan Rogue II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior lights system air conditioning, defogger systems (1 of 1)
56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 BAT SAVER BAT (FUSE)
AIR CONDITIONING SYSTEM
AIRCON SW BLOWER FAN SW HAZARD SW BACK DOOR OPEN SW
ANTI-THEFT SYSTEM
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DR SW AS DR SW RR AUTO LIGHT SENS IN
EXTERIOR LIGHTS SYSTEM AIR CONDITIONING, DEFOGGER SYSTEMS
EXTERIOR LIGHTS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM
FUSE
FUSE, FUSIBLE LINK
FUSIBLE LINK J
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM DOOR LOCKS, HEADLIGHTS SYSTEMS
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
HOT IN ACC OR ON
HOT IN ON OR START
IMMOB ANT (RX, TX)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
POWER TOPS, POWER WINDOWS SYSTEMS
PPL
PPL BACK DOOR OPENER OUT
PPL LOCK OUT ALL UNLCK OUT OTHER GND PWR WDW OUT RAP PWR WDW OUT BAT BAT FL
RED WIRE
RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ROOM LAMP OUT
RR WIP MTR OUT
SECURITY IND OUT
TAN WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TRUNK, TAILGATE, FUEL DOORS SYSTEM WIPER/WASHER SYSTEM
UNLOCK OUT (DR) FLASHER OUT (LEFT) FLASHER OUT (RIGHT)
WARNING SYSTEMS
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Body control modules circuit -> EXTERIOR LIGHTS SYSTEM AIR CONDITIONING, DEFOGGER SYSTEMS
