Nissan Rogue II (2013-2016) control sig wiring diagram
This page shows the only wiring diagram for the component.control sig, which is found in the car Nissan Rogue II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
control sig wiring diagram (1 of 1)
AV COMM (H)
AV COMM (L)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CAN-H CAN-L VEH SPD SIG PNK WIRE
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE) (TOP OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CONTROL SIG
GRN WIRE
GRY WIRE
HOT IN ON OR START FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE 1
IGNITION
LT BLU WIRE
LT GRN WIRE
MICRO GND
MICRO SIG +
MICRO VCC
PPL
SHIELD
SHIELD 69 59 58 6 7 8
SHIELD SHIELD SHIELD 1 2 3
SIG
STRG SW A
STRG SW B
STRG SW GND
TAN WIRE
TEL ADAPTER UNIT (W/ TELEPHONE)
TEL ANT SIG
TEL ANTENNA
TEL ON SIG
VEH SPEED
W/ TELEPHONE
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, base without navigation (2 of 3) -> CONTROL SIG
