Nissan Rogue II (2013-2016) back-up lamp assembly lh Wiring diagrams
This page contains all the electrical diagrams for the component. back-up lamp assembly lh, in which he is found in the car Nissan Rogue II (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
back-up lamp assembly lh wiring diagram (1 of 3)
Go to component -> Backup lamps circuit -> BACK-UP LAMP ASSEMBLY LH
back-up lamp assembly lh wiring diagram (2 of 3)
ASSEMBLY
BACK-UP LAMP ASSEMBLY LH
BACK-UP LAMP ASSEMBLY RH
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISTRIBUTION
ENGINE COMPT)
ENGINE ROOM
FRONT COMBINATION LAMP LH
FRONT COMBINATION LAMP RH
FUSE 10
FUSE BLOCK (J/B) (LEFT END OF DASH)
GRY WIRE
HEADLIGHT
HOT AT ALL TIMES
HOT IN ON OR START
INTELLIGENT
LED DAYTIME, PARKING LAMP CONTROL MODULE
LICENSE PLATE LAMP LH
LICENSE PLATE LAMP RH
LT GRN WIRE
MODULE
OF DASH)
PANEL)
PILLAR)
PNK WIRE
POWER
PPL/BRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
QUARTER
RED WIRE
RR COMBINATION LAMP LH
SIDE MARKER
SMART FET
STOP
STOP LAMP SWITCH
TAIL
TAN WIRE
TURN SIGNAL
VIO WIRE
W/ HALOGEN HEADLAMP W/ LED HEADLAMP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> BACK-UP LAMP ASSEMBLY LH
back-up lamp assembly lh wiring diagram (3 of 3)
3 4 W/O BOSE AUDIO W/ BOSE AUDIO
AUDIO UNIT (W/O NAVIGATION)
AV CONTROL UNIT (W/ NAVIGATION)
AWD CONTROL MODULE
BACK-UP LAMP ASSEMBLY LH
BACK-UP LAMP ASSEMBLY RH
BEHIND LEFT QUARTERPANEL)
BLU WIRE
BRN WIRE
FROM FUSIBLE LINK C (FUSIBLE LINK BOX (BATTERY)) (DIAGRAM 1 OF 6)
FROM FUSIBLE LINK D (FUSIBLE LINK BOX (BATTERY)) (DIAGRAM 1 OF 6)
FROM FUSIBLE LINK E (FUSIBLE LINK BOX (BATTERY)) (DIAGRAM 1 OF 6)
FRONT COMBINATION LAMP LH
FRONT COMBINATION LAMP RH
FRONT FOG LAMP LH
FRONT FOG LAMP RH
FUSE 13 FUSE 18
FUSE 2 FUSE 6
FUSE 26
FUSE 41
FUSE 9
FUSE BLOCK (J/B) (LEFT END OF DASH)
GRN WIRE
GRY WIRE
LICENSE PLATE LAMP LH
LICENSE PLATE LAMP RH
LT BLU WIRE
LT GRN WIRE
NATS AWD ANTENNA CONTROL AMP MODULE (W/O INTELLIGENT KEY SYSTEM)
PNK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
QUARTER PANEL)
REAR COMBINATION LAMP LH
REAR COMBINATION LAMP RH
REAR DATA LINK CARGO CONNECTOR POWER SOCKET
RED WIRE
ROOM COMBINATION LAMP RELAY METER
SMART FET
STARTER CUT RELAY (IN FUSE,FUSIBLE LINK BOX AND RELAY BOX 2)
STARTER MOTOR
STARTER RELAY
TAN WIRE
TO FRONT WIPER RELAY (IPDM E/R) (DIAGRAM 5 OF 6)
TO FUSE 14 (FUSE BLOCK (J/B)) (DIAGRAM 3 OF 6)
TO IGNITION RELAY-1 (IPDM E/R) (DIAGRAM 6 OF 6)
TRANSMISSION RANGE SWITCH
VIO WIRE
W/ HALOGEN HEADLAMPS W/ LED HEADLAMPS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> BACK-UP LAMP ASSEMBLY LH
