Nissan Rogue II (2013-2016) 81 82 i key sw i starter sw Wiring diagrams
This page contains all the electrical diagrams for the component. 81 82 i key sw i starter sw, in which he is found in the car Nissan Rogue II (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 81 82 i key sw i starter sw (1 of 2)
1 2 W/ POWER BACK DOOR W/O POWER BACK DOOR
161 162 170 171 I PWR ECU O PWM ROOMLAMP 1 I GND 1 I GND 2
50 51 52 53 57 60 80 I RR DOOR SW I TGATE SW I RL DOOR SW
81 82 I KEY SW I STARTER SW
95 104 105 I SHORTING PIN I DR KNOB SW I IGN SW
AUTOMATIC BACK DOOR CLOSE SWITCH (BOTTOM LEFT OF BACK DOOR) (W/ POWER BACK DOOR)
BACK DOOR LOCK ASSEMBLY (BOTTOM CENTER OF BACK DOOR)
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN-H CAN-L PNK WIRE
COMPUTER DATA LINES SYSTEM
DOOR
FRONT DOOR LOCK ASSEMBLY LH
FRONT DOOR SWITCH LH (IN LEFT SIDE "B" PILLAR)
FRONT DOOR SWITCH RH (IN RIGHT SIDE "B" PILLAR)
FUSE 7 FUSE 14
FUSE BLOCK FUSE 18 (J/B) (LEFT END OF DASH)
GRY WIRE
HOT AT ALL TIMES
I DOORLOCK SW I DOORUNLOCK SW
IGNITION SWITCH
INTERIOR SWITCH (ALL)
INTERIOR SWITCH (DOOR)
KEY SWITCH
LOCK
LT BLU WIRE
LT GRN WIRE
LT LT
LUGGAGE ROOM LAMP
MAIN FRONT POWER POWER WINDOW WINDOW AND DOOR SWITCH RH LOCK/ UNLOCK SWITCH
MAP LAMP ASSEMBLY
O PWM ROOMLAMP 5
OFF
OFF 3 2 ON PNK PNK PNK WIRE
OFF ON
ON LAMP SWITCH RH
ON OFF
ON OFF LAMP SWITCH LH
ON ON OFF OFF
ON PERSONAL LAMP RH PNK WIRE
PERSONAL LAMP LH DOOR
PNK WIRE
PPL/RED WIRE
REAR DOOR SWITCH LH (IN LEFT SIDE "C" PILLAR)
REAR DOOR SWITCH RH (IN RIGHT SIDE "C" PILLAR)
RED WIRE
RIGHT END OF DASH)
ROOM LAMP (W/O MOON ROOF)
ROOM LAMP RELAY (LOWER CENTER OF DASH)
TAN WIRE
UNLOCK
VANITY MIRROR LAMP LH VANITY MIRROR LAMP RH
VIO WIRE
W/ MOON- ROOF
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, without intelligent key -> 81 82 I KEY SW I STARTER SW
Wiring diagram 81 82 i key sw i starter sw (2 of 2)
81 82 I KEY SW I STARTER SW
BATTERY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLK/RED WIRE
BLU WIRE
FUSE
FUSE 46
FUSE/FUSIBLE LINK AND RELAY BOX 1 (LEFT SIDE OF ENGINE COMPARTMENT)
FUSIBLE LINK A
FUSIBLE LINK B
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK C
GENERATOR
GRN WIRE
GRY WIRE
I IGN SW
IGNITION RELAY 1
IGNITION SWITCH
KEY SWITCH
LT BLU WIRE
NCA WIRE
O STCUT RL
OFF
ON OFF
POWER DISTRIBUTION SYSTEM
PPL/RED WIRE
RIGHT END OF DASH)
STARTER CUT RELAY (IN FUSE/ FUSIBLE LINK, RELAY BOX 2)
STARTER MOTOR (LOWER LEFT REAR OF ENGINE)
STARTER RELAY
TAN WIRE
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF TRANSMISSION)
WHT WIRE
YEL WIRE
Go to component -> Starting circuit, without intelligent key (2 of 1) -> 81 82 I KEY SW I STARTER SW
