Nissan Rogue II (2013-2016) 2 4 1 signal power gnd ppl Wiring diagram

+BATT +IGN GND (POWER) 12 13 PNK DR SW AS DR SW RR WIRE 18 19 20 KEYLESS SENS GND KEYLESS TUNER PWR KEYLESS TUNER SIG PPL 2 4 1 SIGNAL POWER GND PPL 43 53 47 48 PPL PPL BACK DOOR SW BACK DOOR OPENER OUT DR SW DR DR SW RL BACK DOOR LOCK ASSEMBLY (BOTTOM CENTER OF BACK DOOR) BACK DOOR SWITCH BAT (F/L) BAT FUSE BATT SAVER BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CDL UNLOCK SW COMPUTER DATA LINES SYSTEM D/L UNLOCK DR DOOR UNLOCK OUT (OTHER) DRIVER SIDE FRONT DOOR SWITCH (LEFT "B" PILLAR) FLASHER OUT (LEFT) FLASHER OUT (RIGHT) FUSE FUSE 61 FUSE 62 FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH) FUSE, FUSIBLE LINK, RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK J GRN WIRE GRY WIRE HAZARD SW HORN RLY HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START IGNITION RELAY KEY CYL LOCK SW KEY CYL UNLOCK SW KEY SW LT GRN WIRE LUGGAGE LMP OT OPENER ACTUATOR PASSENGER SIDE FRONT DOOR LOCK ACTUATOR (REAR OF FRONT PASSENGER'S DOOR) PNK CAN-L WIRE PNK CDL LOCK SW WIRE PNK WIRE PPL PPL DOOR LOCK OUT ALL RED WIRE REMOTE KEYLESS ENTRY RECEIVER ROOM LAMP OUT SWITCH (LEFT "C" PILLAR) WHT WIRE YEL WIRE
