Nissan Rogue II (2013-2016) 2 1 w/ bose audio w/o bose audio Wiring diagram

10 9 PNK WIRE 14 26 PNK CAN-L CAN-H WIRE 16 8 PNK CAN-L CAN-H WIRE 17 8 17 7 17 8 CAN-L CAN-H 18 17 PNK WIRE 2 1 CAN-H CAN-L PNK WIRE 2 1 PNK WIRE 2 1 W/ BOSE AUDIO W/O BOSE AUDIO 23 33 PNK CAN-L CAN-H WIRE 23 7 CAN-L CAN-H 24 12 PNK CAN-L CAN-H WIRE 28 28 27 15 5 10 12 CAN-L CAN-H 3 4 W/O LANE DEPARTURE PREVENTION SYSTEM W/ LANE DEPARTURE PREVENTION SYSTEM 31 11 CAN-L CAN-H 4 3 CAN-H CAN-L PNK WIRE 42 41 PNK WIRE 46 45 CAN-H CAN-L PNK WIRE 5 2 CAN-H CAN-L PNK WIRE 5 6 CAN L CAN H 6 7 CAN L CAN H 60 80 PNK WIRE 9 8 CAN-L CAN-H 99 100 PNK CAN-L CAN-H WIRE A/C AUTO AMPLIFIER (BOTTOM LEFT SIDE OF HVAC UNIT) ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (RIGHT REAR OF ENGINE COMPT) AIRBAG DIAGNOSIS SENSOR UNIT (UNDER CENTER CONSOLE) AROUND VIEW MONITOR CONTROL UNIT AUTOMATIC BACK DOOR CONTROL MODULE (BEHIND LEFT REAR QUARTERPANEL) AV CONTROL UNIT AWD CONTROL MODULE (BEHIND LEFT END OF REAR BUMPER) BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) CAN-H CAN-L BLK WIRE BLU WIRE CAN-L CAN-H CHASSIS CONTROL MODULE (BEHIND GLOVE BOX) COMBINATION METER DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DISTANCE SENSOR (BEHIND RIGHT SIDE OF FRONT GRILLE) ECM (LEFT FRONT OF ENGINE COMPT) EPS CONTROL UNIT (BEHIND LEFT SIDE OF DASH) FRONT AIR CONTROL FUSE 30 FUSE 6 FUSE BLOCK (J/B) (LEFT END OF DASH) HOT AT ALL TIMES HOT IN ON OR START PNK 40 39 WIRE PNK WIRE RED WIRE RIGHT END OF DASH) STEERING ANGLE SENSOR (ON STEERING COLUMN) TCM (TRANSMISSION CONTROL MODULE) (LEFT REAR OF ENGINE COMPARTMENT) UNIFIED METER CONTROL UNIT W/ AUTO A/C W/O AUTO A/C WHT WIRE YEL WIRE
