Nissan Rogue II (2013-2016) 14 26 pnk computer data lines system can-l can-h Wiring diagram
This page shows the only wiring diagram for the component.14 26 pnk computer data lines system can-l can-h, which is found in the car Nissan Rogue II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 14 26 pnk computer data lines system can-l can-h (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 AWD SOL+ AWD SOL-
14 26 PNK COMPUTER DATA LINES SYSTEM CAN-L CAN-H WIRE
42 41 PNK CAN-L CAN-H WIRE
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (RIGHT REAR OF ENGINE COMPARTMENT)
AWD AUTO
AWD CONTROL MODULE (BEHIND LEFT END OF REAR BUMPER)
AWD LOCK
AWD LOCK SWITCH
AWD SOLENOID
BLK WIRE
BLU WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 30
FUSE 6
FUSE 9
FUSE BLOCK (J/B) (LEFT END OF DASH)
HOT AT ALL TIMES
HOT IN ON OR START
IGN CAN-H SOL BATT GND GND
ILL
LOCK SW VB CAN-L
LT BLU WIRE
PNK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/RED WIRE
RED WIRE
RIGHT END OF DASH)
WHT WIRE
YEL (OR WIRE
YEL WIRE
Go to component -> Awd circuit -> 14 26 PNK COMPUTER DATA LINES SYSTEM CAN-L CAN-H WIRE
