Nissan Rogue I facelift (2010-2013) steering switch illumination Wiring diagram

23 24 LIGHT + LIGHT - 39 40 4 3 2 5 6 32 33 34 35 36 CAN-H CAN-L PNK WIRE 70 57 67 BAT (F/L) BAT (FUSE) GND A/C AMPLIFIER (BEHIND CENTER OF DASH) AUDIO UNIT AUTO AMPLIFIER AWD LOCK SWITCH (ILLUMINATION) (IF EQUIPPED) BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH) BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CVT SHIFT SELECTOR FUSE 10 FUSE 3 (J/B) (BEHIND LEFT END OF DASH) FUSE 45 FUSE 9 FUSE BLOCK FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK J GLOVE BOX LAMP) GND GND B+ GRN WIRE GRY WIRE HAZARD SWITCH ILLUMINATION HOT AT ALL TIMES HOT IN ON OR START IGN CAN-H CAN-L ILL OUT ILLUMINATION IPDM E/R (INTELLIGENT POWER DISTRIBUTION LEFT HEATED SEAT SWITCH (ILLUMINATION) (IF EQUIPPED) LT BLU WIRE LT GRN WIRE MAP LAMP (MOOD LAMP) (IF EQUIPPED) NAVIGATION CONTROL UNIT (IF EQUIPPED) NCA WIRE ORG/ WIRE PNK WIRE PPL PPL 3 RED WIRE RIGHT HEATED SEAT SWITCH (ILLUMINATION) (IF EQUIPPED) STEERING SWITCH ILLUMINATION TAIL LAMP RELAY MODULE ENGINE ROOM) (LEFT SIDE OF ENGINE COMPT) TAIL/L RLY VDC OFF SWITCH (ILLUMINATION) (W/ VDC) WHT WIRE YEL WIRE
