Nissan Rogue I facelift (2010-2013) primary secondary sensor Wiring diagram
This page shows the only wiring diagram for the component.primary secondary sensor, which is found in the car Nissan Rogue I facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram primary secondary sensor (1 of 1)
21 22 CAN-H CAN-L PNK WIRE
ACCEL/RES SWITCH
ACCELERATOR PEDAL POSITION SENSOR
ACSD STEERING SWITCH
ASCD BRAKE SWITCH (ON BRAKE PEDAL BRACKET)
AVCC-TPS
BLK WIRE
BLU WIRE
BRAKE BNCSW VEHCAN-H VEHCAN-L GNDA-ASCDSW ASCDSW
CANCEL SWITCH
COAST/ SET SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE IND, SET IND
ECM (LEFT SIDE OF ENGINE COMPT)
ELECTRIC THROTTLE CONTROL ACTUATOR
FUSE
FUSE 61
GNDA-TPS
GRN WIRE
GRY WIRE
HOT AT ALL ALL TIMES
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START FUSE BLOCK (J/B) FUSE (BEHIND LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
MAIN SWITCH
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
PPL 87 82 100 83 81 84 106 110 98 97 92 85
PPL PNK 15 2 WIRE
PRIMARY SECONDARY SENSOR
RED WIRE
SECONDARY SPEED SENSOR
SENSOR 1
SENSOR 2
TCM (TRANSMISSION CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
THROTTLE CONTROL MOTOR
THROTTLE CONTROL MOTOR RELAY
THROTTLE POSITION SENSOR
TOP OF TRANSMISSION)
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit -> PRIMARY SECONDARY SENSOR
