Nissan Rogue I facelift (2010-2013) left low headlamp Wiring diagrams
This page contains all the electrical diagrams for the component. left low headlamp, in which he is found in the car Nissan Rogue I facelift (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left low headlamp (1 of 2)
BLK WIRE
BLU WIRE
FRONT FOG LAMP RELAY
FUSE 43
FUSE 44
FUSE 49
FUSE 50
FUSE 61 FUSE 62
FUSE 65
GRN WIRE
HEAD LAMP (LOW) RELAY
HEAD LAMP HIGH RELAY
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
LEFT FRONT FOG LAMP
LEFT HIGH HEADLAMP
LEFT LOW HEADLAMP
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HIGH HEADLAMP
RIGHT LOW HEADLAMP
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, with drl (2 of 2) -> LEFT LOW HEADLAMP
Wiring diagram left low headlamp (2 of 2)
BLK WIRE
BLU WIRE
FRONT FOG LAMP RELAY
FUSE 43
FUSE 44 FUSE 49
FUSE 50
FUSE 61
FUSE 62
FUSE 65
GRN WIRE
HEAD LAMP (LOW) RELAY
HEAD LAMP HIGH RELAY
HID CONT
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
LEFT FRONT FOG LAMP
LEFT LEFT HIGH LOW HEADLAMP HEADLAMP
LEFT LOW HEADLAMP
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RIGHT FRONT FOG LAMP
RIGHT HIGH HEADLAMP
RIGHT LOW HEADLAMP
WHT WIRE
XENON
YEL WIRE
Go to component -> Headlights circuit, without drl (2 of 2) -> LEFT LOW HEADLAMP
