Nissan Rogue I facelift (2010-2013) hot at all times fuse, fusible link block fusible link j Wiring diagram
This page shows the only wiring diagram for the component.hot at all times fuse, fusible link block fusible link j, which is found in the car Nissan Rogue I facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times fuse, fusible link block fusible link j (1 of 1)
1 3 PPL
60 61 LH FLASHER OUT RH FLASHER OUT
70 57 67 BAT (F/L) BAT (FUSE) GND (POWER)
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 1
FUSE 20
FUSE 3
FUSE 45
FUSE 46
FUSE 9
FUSIBLE LINK C
FUSIBLE LINK HOLDER
GND (SIGNAL)
GRN WIRE
GRY WIRE
HAZARD SWITCH
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (J/B) FUSE 11 (BEHIND LEFT END OF DASH)
HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK J
HOT IN ACC OR ON
HOT IN ON OR START
IGN
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) (LEFT SIDE
LEFT FRONT COMBINATION LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LT BLU WIRE
LT GRN WIRE
OF ENGINE COMPT)
ORG/ WIRE
PARKING
PNK COMPUTER DATA LINES SYSTEM WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
SHIFT INTERLOCK SYSTEM
STOP
STOPLIGHT SWITCH (ON BRAKE PEDAL BRACKET)
TAIL LAMP RELAY
TAIL/L RLY
TURN
TURN IND, BUZZER
TURN SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK J
