Nissan Rogue I facelift (2010-2013) evap ecm ecm air canister flow vent sensor control valve Wiring diagram
This page shows the only wiring diagram for the component.evap ecm ecm air canister flow vent sensor control valve, which is found in the car Nissan Rogue I facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram evap ecm ecm air canister flow vent sensor control valve (1 of 1)
A/C AMPLIFIER (MANUAL A/C)
AWD LOCK SWITCH (AWD)
BLU WIRE
BRN WIRE
COMBINATION HAZARD AUDIO SWITCH SWITCH UNIT (SPIRAL CABLE)
CONDENSER
ECM RELAY
ENGINE ROOM) (LEFT SIDE OF ENGINE COMPT)
EVAP ECM ECM AIR CANISTER FLOW VENT SENSOR CONTROL VALVE
FROM FUSIBLE LINK C (FUSIBLE LINK HOLDER) (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK E (FUSIBLE LINK HOLDER) (DIAGRAM 1 OF 4)
FRONT FOG LAMP RELAY
FUSE 45 FUSE 46
FUSE 61
GLOVE BOX LAMP)
GRN WIRE
GRY WIRE
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
IGNITION COIL 3
IGNITION IGNITION COIL 2 COIL 1
IGNITION INTAKE COIL 4 VALVE TIMING CONTROL SOLENOID VALVE
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE
LEFT FRONT COMBINATION LAMP
LEFT REAR LEFT LICENSE COMBINATION PLATE LAMP LAMP
LEFT RIGHT HEATED HEATED SEAT SEAT SWITCH SWITCH (IF (IF EQUIPPED) EQUIPPED)
MAP LAMP (W/ MOOD LAMP)
MASS EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
NATS ECM ANTENNA AMPLIFIER
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
TAIL LAMP RELAY
THROTTLE CONTROL MOTOR RELAY
TO FUSE 48 (IPDM E/R) (DAIGRAM 4 OF 4)
TO FUSE 55 FUSE 62 (IPDM E/R) (DAIGRAM 4 OF 4)
VDC OFF SWITCH (IF EQUIPPED)
W/ DISPLAY 9 9 9 AUDIO W/ IPOD W/ BASE AUDIO W/O IPOD
W/ POWER TRANSISTOR
Go to component -> Power distribution circuit (2 of 4) -> EVAP ECM ECM AIR CANISTER FLOW VENT SENSOR CONTROL VALVE
