Nissan Rogue I facelift (2010-2013) door mirror remote control switch Wiring diagram
This page shows the only wiring diagram for the component.door mirror remote control switch, which is found in the car Nissan Rogue I facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door mirror remote control switch (1 of 1)
BLK WIRE
BLU WIRE
DEFOGGER SYSTEM
DOOR MIRROR REMOTE CONTROL SWITCH
DOWN
DRIVER SIDE DOOR MIRROR
FUSE
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
LEFT
LEFT UP
LT BLU WIRE
LT GRN WIRE
MIRROR SWITCH
OFF
OFF OFF
PASSENGER SIDE DOOR MIRROR
PPL
RED WIRE
RIGHT
RIGHT DOWN
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> DOOR MIRROR REMOTE CONTROL SWITCH
