Nissan Rogue I facelift (2010-2013) cvt unit Wiring diagram
This page shows the only wiring diagram for the component.cvt unit, which is found in the car Nissan Rogue I facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cvt unit (1 of 1)
AUTO
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN-H CAN-L PNK WIRE
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CVT CHECK IND
CVT FLUID TEMP SENS PRI OIL PRESS SENS SEC OIL PRESS SENS
CVT SHIFT SELECTOR
CVT UNIT
DISTRIBUTION MODULE ENGINE ROOM) (LEFT SIDE OF ENGINE COMPT)
DOWN
FUSE 38 LINK, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 58
FUSE 60
FUSE, FUSIBLE
GRN WIRE
GRN/ LT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IPDM E/R (INTELLIGENT POWER
L/U SELECT SOLENOID VALVE CLUTCH SOL VALVE SEC LINER SOL PRESSURE LINER SOL
LT BLU WIRE
LT GRN WIRE
MANUAL
MODE
MODE SELECT SWITCH (W/ MANUAL
MODE) 8 7 9
NCA WIRE
ORG/ WIRE
OVERDRIVE CONTROL SWITCH (W/O MANUAL MODE)
P RANGE SW
PADDLE SHIFT-DOWN SWITCH (W/ MANUAL MODE)
PNK WIRE
POSITION SELECT SWITCH (W/ MANUAL
PPL
PRIMARY PRESSURE SENSOR
PRIMARY SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
RED WIRE
ROM ASSEMBLY
SECONDARY PRESSURE SENSOR
SECONDARY SPEED SENSOR (TOP OF TRANSMISSION)
SENSOR GND
STARTING/ CHARGING SYSTEM
STEP MOTOR
TCM (TRANSMISSION CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
TORQUE LOCK-UP CONVERTER SELECT CLUTCH SOLENOID SOLENOID VALVE VALVE
VIGN BATT VIGN
WHT WIRE
YEL WIRE
Go to component -> A/t circuit -> CVT UNIT
