Instrument illumination circuit for Nissan Rogue I (2007-2010)

23 24 LIGHT + LIGHT - 39 40 4 3 2 5 6 32 33 34 35 36 CAN-H CAN-L PNK WIRE 70 57 67 BAT (F/L) BAT (FUSE) GND A/C AMPLIFIER (BEHIND CENTER OF DASH) AUDIO UNIT AWD LOCK SWITCH (ILLUMINATION) (IF EQUIPPED) BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH) BRN WIRE CAN L CAN-H COMBINATION METER COMBINATION SWITCH COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CONTROL DEVICE ILLUMINATION (UNDER CENTER CONSOLE) DOOR MIRROR REMOTE CONTROL SWITCH (ILLUMINATION) FUSE 10 FUSE 3 FUSE 45 FUSE 9 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK J GLOVE BOX LAMP) GND GND GND B+ GRN WIRE GRY WIRE HAZARD SWITCH ILLUMINATION HEADLAMP AIMING SWITCH ILLUMINATION (IF EQUIPPED) HOT AT ALL TIMES HOT IN ON OR START IGN CAN-H CAN-L ILL (-) OUT LEFT HEATED SEAT SWITCH (ILLUMINATION) (IF EQUIPPED) LT BLU WIRE LT GRN WIRE MAP LAMP (MOOD LAMP) (IF EQUIPPED) NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RIGHT HEATED SEAT SWITCH (ILLUMINATION) (IF EQUIPPED) STEERING SWITCH ILLUMINATION TAIL LAMP RELAY TAIL/L RLY UNIFIED METER CONTROL UNIT UNIFIED METER CONTROL UNIT (W/ METER ILLUMINATION, ILLUMINATION CONTROL SWITCH) VDC OFF SWITCH (ILLUMINATION) (W/ VDC) VIO WIRE WHT WIRE YEL WIRE
