Nissan Rogue I (2007-2010) tire pressure indicator Wiring diagram
This page shows the only wiring diagram for the component.tire pressure indicator, which is found in the car Nissan Rogue I (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tire pressure indicator (1 of 1)
2 4 1 SIG POWER GND PPL
20 19 18 39 40 4 3 2 5 6 32 33 34 35 36 TUNER SIG TUNER OUT SENS GND PPL
70 57 67 BAT FL BAT FL GND
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH)
BRN WIRE
CAN-H CAN-L PNK WIRE
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
DR SW (DR)
DRIVER SIDE FRONT DOOR SWITCH
DRIVER SIDE FRONT TIRE PRESSURE SENSOR
END OF DASH)
FUSE 10
FUSE 3
FUSE 9
FUSE BLOCK (J/B) (BEHIND LEFT
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK J
GND GND GND B+
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN CAN-H CAN-L
LEFT REAR TIRE PRESSURE SENSOR
LT GRN WIRE
ORG/ WIRE
PASSENGER SIDE FRONT TIRE PRESSURE SENSOR
PNK WIRE
PPL
RED WIRE
REMOTE KEYLESS ENTRY RECEIVER (TIRE PRESSURE RECEIVER)
RIGHT REAR TIRE PRESSURE SENSOR
TIRE PRESSURE INDICATOR
TIRE PRESSURE WARNING CHECK SWITCH
TPMS MODE
UNIFIED METER CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> TIRE PRESSURE INDICATOR
