Nissan Rogue I (2007-2010) pnk 46 52 tw gnda-tw Wiring diagram
This page shows the only wiring diagram for the component.pnk 46 52 tw gnda-tw, which is found in the car Nissan Rogue I (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk 46 52 tw gnda-tw (1 of 1)
26 27 PNK WIRE
3 4 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR 1 (LEFT FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 2 (RIGHT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 1
COOLING FAN RELAY 2
COOLING FAN RELAY 3
COOLING FAN RELAY 4
COOLING FAN RELAY 5
ECM (LEFT SIDE OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR
FUSE 61
FUSE 62
FUSE 63
FUSE, FUSIBLE LINK, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK M
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
LT GRN WIRE
ORG/ WIRE
PNK 46 52 TW GNDA-TW WIRE
PNK 97 98 VEHCAN-L VEHCAN-H WIRE
PNK WIRE
VIO WIRE
WHT WIRE
Go to component -> Cooling fan circuit -> PNK 46 52 TW GNDA-TW WIRE
