Nissan Rogue I (2007-2010) park/ primary neutral speed position sensor switch Wiring diagram
This page shows the only wiring diagram for the component.park/ primary neutral speed position sensor switch, which is found in the car Nissan Rogue I (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park/ primary neutral speed position sensor switch (1 of 1)
A/C RELAY
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
AWD CONTROL UNIT (AWD)
BLK WIRE
BRN WIRE
COOLING FAN RELAY 1
COOLING FAN RELAY 2
COOLING FAN RELAY 3
COOLING FAN RELAY 5
COOLING HEATED FAN OXYGEN RELAY-4 SENSOR 3 (CALIFORNIA)
FROM FUSIBLE LINK C (FUSIBLE LINK HOLDER) (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK E (FUSIBLE LINK HOLDER) (DIAGRAM 1 OF 4)
FROM FUSIBLE LINK K (FUSE, FUSIBLE LINK BLOCK) (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (DIAGRAM 3 OF 4)
FROM STEEERING ANGLE SENSOR (DIAGRAM 3 OF 4)
FRONT WIPER RELAY
FUEL FUEL INJECTOR INJECTOR
FUEL INJECTOR
FUEL PUMP RELAY
FUSE 48
FUSE 51
FUSE 55
FUSE 56
FUSE 57 FUSE 58
FUSE 59
FUSE 60
FUSE 63
FUSE 64
G SENSOR (AWD W/O VDC)
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR 2
IGNITION RELAY
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK/ PRIMARY NEUTRAL SPEED POSITION SENSOR SWITCH
PARK/NEUTRAL POSITION SWITCH
REAR WINDOW DEFOGGER RELAY
RED WIRE
SECONDARY SPEED SENSOR
STARTER RELAY
TCM (TRANSMISSION CONTROL MODULE)
VIO WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> PARK/ PRIMARY NEUTRAL SPEED POSITION SENSOR SWITCH
