Nissan Rogue I (2007-2010) +ing speed sens +b Wiring diagram
This page shows the only wiring diagram for the component.+ing speed sens +b, which is found in the car Nissan Rogue I (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +ing speed sens +b (1 of 1)
+ING SPEED SENS +B
22 21 30 PNK CAN L CAN H VSS (2 PULSE) WIRE
6 5 4 3 2 1 GND
70 57 BAT FL BAT FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH)
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER SIDE FRONT DOOR SWITCH
FUSE
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK J
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
ORG/ WIRE
PASSENGER SIDE FRONT DOOR SWITCH
PNK DR SW (AS) WIRE
PNK DR SW DR WIRE
PNK WIRE
PWR WDW BAT
PWR WDW RAP
RED WIRE
SUNROOF MOTOR ASSEMBLY,
SUNROOF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> +ING SPEED SENS +B
