Nissan Rogue I (2007-2010) driver side sliding motor Wiring diagram
This page shows the only wiring diagram for the component.driver side sliding motor, which is found in the car Nissan Rogue I (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side sliding motor (1 of 1)
39 40 COMPUTER DATA LINES SYSTEMS CAN-H CAN-L PNK WIRE
67 70 57 69 GND BAT FL BAT (FUSE) POWER WDW
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT END OF DASH)
BWD
BWD DWN
DOWN
DRIVER SIDE DRIVER SIDE RECLINING MOTOR LIFTING MOTOR
DRIVER SIDE FRONT SEAT
DRIVER SIDE POWER SEAT
DRIVER SIDE SLIDING MOTOR
FUSE BEHIND LEFT END OF DASH)
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK J
FWD BWD UP
FWD UP
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LT GRN WIRE
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
ORG/ WIRE
PNK WIRE
RECLINING LIFTING SWITCH SWITCH
RED WIRE
RED/BLU WIRE
SLIDING SWITCH
SWITCH
VIO WIRE
YEL WIRE
Go to component -> Power seat circuit -> DRIVER SIDE SLIDING MOTOR
