Nissan Rogue I (2007-2010) back door opener switch assembly Wiring diagram
This page shows the only wiring diagram for the component.back door opener switch assembly, which is found in the car Nissan Rogue I (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back door opener switch assembly (1 of 1)
40 39 30 PNK CAN-L CAN-H DOOR OPEN SW WIRE
43 53 BACK DOOR SW DOOR OPENER OUT
70 57 67 BAT (F/L) BAT (FUSE) GND
BACK DOOR OPENER SWITCH ASSEMBLY
BACK DOOR SW
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK J
GRN WIRE
HOT AT ALL TIMES
LT GRN WIRE
OPENER ACTUATOR BACK DOOR LOCK ASSEMBLY
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Back door opener circuit -> BACK DOOR OPENER SWITCH ASSEMBLY
