Nissan Rogue I (2007-2010) 1 2 3 4 5 6 7 8 9 10 batt gnd ig Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 7 8 9 10 batt gnd ig, which is found in the car Nissan Rogue I (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 7 8 9 10 batt gnd ig (1 of 1)
1 2 3 4 5 6 7 8 9 10 BATT GND IG
BLK WIRE
BLU WIRE
CAN L
COMPUTER DATA LINES SYSTEM
EPS CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
FUSE
FUSE BLOCK (J/B) (BEHIND LEFT END OF DASH)
FUSE, FUSIBLE LINK, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK F
HOT AT ALL TIMES
HOT IN ON OR START
PNK CAN-H WIRE
RED WIRE
WHT WIRE
Go to component -> Electronic power steering circuit -> 1 2 3 4 5 6 7 8 9 10 BATT GND IG
