Nissan Rogue Sport I facelift (2019-2024) mirror select sw lh Wiring diagram
This page shows the only wiring diagram for the component.mirror select sw lh, which is found in the car Nissan Rogue Sport I facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror select sw lh (1 of 1)
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
BAT POWER SUPPLY (FUSE)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAMERA
CAN L
CAN-H
CIRCUIT BREAKER
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DR DOOR SW
DRIVER SIDE DOOR MIRROR
FRONT DOOR SWITCH (DRIVER SIDE)
FUSE 6
FUSE 7
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK M
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MIR SENS (LH VERT)
MIR SENS (RH VERT)
MIR SW (LEFTWARD)
MIRROR MTR LH (COMMON-MC)
MIRROR MTR LH (LEFT-MB)
MIRROR MTR LH (UP-MA)
MIRROR MTR RH (COMMON-MC)
MIRROR MTR RH (LEFT-MB)
MIRROR MTR RH (UP-MA)
MIRROR SELECT SW LH
MIRROR SELECT SW RH
MIRROR SENSOR LH HOR
MIRROR SW (DOWNWARD)
MIRROR SW (RIGHTWARD) MIRROR SENSOR RH HOR
MIRROR SW (UPWARD)
NAVIGATION SYSTEM
PASSENGER SIDE DOOR MIRROR
PNK WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/TAN WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
RIGHT END OF DASH)
RX/TX
SENSOR GND
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (1 of 3) -> MIRROR SELECT SW LH
