Nissan Rogue Sport I facelift (2019-2024) chassis/ its comm-l chassis/ its comm-l Wiring diagram
This page shows the only wiring diagram for the component.chassis/ its comm-l chassis/ its comm-l, which is found in the car Nissan Rogue Sport I facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram chassis/ its comm-l chassis/ its comm-l (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SWITCH INDICATOR
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
CAN L
CAN-H
CHASSIS CONTROL MODULE
CHASSIS/ ITS COMM-H
CHASSIS/ ITS COMM-L CHASSIS/ ITS COMM-L
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DISTANCE SENSOR
ELECTRIC PARKING BRAKE SWITCH
FUSE 30
FUSE 6
FUSE BLOCK (J/B)
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
IGN
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
ITS CAN COMM L
ITS CAN COMM-H
LT BLU WIRE
PNK WIRE
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
RIGHT END OF DASH)
STEERING ANGLE SENSOR (ON STEERING COLUMN)
SW SIG CHASSIS/ ITS COMM-H SW IND SIG
TCM
UNIFIED METER CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Electronic suspension circuit -> CHASSIS/ ITS COMM-L CHASSIS/ ITS COMM-L
