Nissan Rogue Sport I facelift (2019-2024) can-h unified can-l meter control unit Wiring diagram

ADAS CONTROL UNIT (LEFT REAR "D" PILLAR) ADAS CONTROL UNIT 2 (LEFT END OF DASH) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE BSW IND BSW INDICATOR CAN COMM H CAN COMM L CAN COMM-H V-CAN HIGH CAN COMM-L V-CAN LOW CAN L CAN-H CAN-H UNIFIED CAN-L METER CONTROL UNIT COMBINATION METER COMPUTER DATA LINES SYSTEM DISTANCE SENSOR DRIVER ASSISTANCE BUZZER DYNAMIC DRIVER ASSIST SW SIG FRONT CAMERA UNIT (TOP CENTER OF WINDSHIELD) FUSE 14 FUSE 29 FUSE 30 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED IGN PWR SPLY ITS CAN COMM L ITS CAN COMM-H ITS CAN COMM-H ITS-CAN HIGH ITS CAN COMM-L ITS-CAN LOW ITS CAN-H ITS CAN-L LEFT BSW INDICATOR LEFT SIDE RADAR LT BLU WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRY WIRE PPL/PNK WIRE PPL/RED WIRE PPL/YEL WIRE PWR SUPPLY RED WIRE RIGHT BSW INDICATOR RIGHT END OF DASH) RIGHT SIDE RADAR RIGHT/LEFT SW SIG TAN WIRE VIO WIRE W/ PROPILOT ASSIST W/O INTELLIGENT AROUND VIEW MONITOR WARNING BUZZER SIG WARNING BUZZER SIG GND WHT WIRE YEL WIRE
