Lane departure warning circuit for Nissan Rogue Sport I (2017-2019)

ADAS CONTROL UNIT (LEFT REAR "D" PILLAR) ADAS CONTROL UNIT 2 (RIGHT END OF DASH) BLK WIRE BLU WIRE BRN WIRE BSW SW IND BSW SW SIG BSW/INTELLIGENT LANE INTERVENTION SWITCH CAN L CAN-H CHASSIS CAN COMM-H CHASSIS CAN COMM-L COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVER ASSISTANCE BUZZER FRONT CAMERA UNIT FUSE 14 FUSE 29 FUSE 30 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED IGN PWR SPLY ITS CAN COMM L ITS CAN COMM-H LDP SW IND LDP SW SIG LT BLU WIRE PPL RED WIRE RIGHT END OF DASH) TAN WIRE VEHICLE CAN COMM-H VEHICLE CAN COMM-L W/O INTELLIGENT LANE INTERVENTION WARNING BUZZER SIG WARNING BUZZER SIG GND WHT WIRE YEL WIRE
