Nissan Rogue Sport I (2017-2019) power window relay Wiring diagram
This page shows the only wiring diagram for the component.power window relay, which is found in the car Nissan Rogue Sport I (2017-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window relay (1 of 1)
BATT PWR SPLY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CIRCUIT BREAKER
CLOSE SIG
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOWN/ OPEN
DRIVER SIDE FRONT DOOR SWITCH
DRV DOOR SW
EARLY PRODUCTION
FUSE 14
FUSE 6
FUSE BLOCK (J/B)
FUSE SW
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK M
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGN ON SIG
LATE PRODUCTION
LT BLU WIRE
PASS DOOR SW
PASSENGER SIDE FRONT DOOR SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER WINDOW RELAY
POWER WINDOWS SYSTEM
PPL
PWR WINDOW RLY CTRL
RED WIRE
RIGHT END OF DASH)
SPEED SIG
SUNROOF MOTOR ASSEMBLY,
SUNROOF SWITCH
TILT DOWN/ SLIDE SIG
UP/ CLOSE
VEHICLE SPEED SIG
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> POWER WINDOW RELAY
