Nissan Rogue Sport I (2017-2019) parking lamp/ daytime running light Wiring diagram
This page shows the only wiring diagram for the component.parking lamp/ daytime running light, which is found in the car Nissan Rogue Sport I (2017-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking lamp/ daytime running light (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL CIRCUIT
GRN WIRE
GRY WIRE
LEFT FRONT COMBINATION LAMP
LEFT LICENSE PLATE LAMP
LEFT TAIL LAMP
LT BLU WIRE
OPTION CONNECTOR 10
PARKING LAMP/ DAYTIME RUNNING LIGHT
PNK WIRE
PPL
PPL/GRY WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT COMBINATION LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
RIGHT TAIL LAMP
SIDE MARKER
SIDE MARKER LAMP
STOP
TAIL
TURN SIGNAL
W/ HALOGEN HEADLAMP W/ LED HEADLAMP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> PARKING LAMP/ DAYTIME RUNNING LIGHT
