Nissan Rogue Sport I (2017-2019) left front fog lamp option connector Wiring diagrams
This page contains all the electrical diagrams for the component. left front fog lamp option connector, in which he is found in the car Nissan Rogue Sport I (2017-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front fog lamp option connector (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
HEADLAMP HIGH
HOT AT ALL TIMES
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FRONT COMBINATION LAMP
LEFT FRONT FOG LAMP
LEFT FRONT FOG LAMP OPTION CONNECTOR
LEFT LOW HEADLAMP
LEFT REAR DOOR SWITCH
LT GRN WIRE
PNK WIRE
PPL
RIGHT FRONT COMBINATION LAMP
RIGHT FRONT FOG LAMP
RIGHT FRONT FOG LAMP OPTION CONNECTOR
RIGHT LOW HEADLAMP
SMART FET
TAN WIRE
W/O OPTION W/ OPTION
WHT WIRE
Go to component -> Headlights circuit, w/ halogen headlamps (2 of 2) -> LEFT FRONT FOG LAMP OPTION CONNECTOR
Wiring diagram left front fog lamp option connector (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
HEADLAMP HIGH
HEADLAMP LOW
HOT AT ALL TIMES
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LED HEADLAMP CONTROL MODULE
LEFT FRONT COMBINATION LAMP
LEFT FRONT FOG LAMP
LEFT FRONT FOG LAMP OPTION CONNECTOR
LEFT REAR DOOR SWITCH
LT GRN WIRE
PNK WIRE
PPL
RIGHT FRONT COMBINATION LAMP
RIGHT FRONT FOG LAMP
RIGHT FRONT FOG LAMP OPTION CONNECTOR
SMART FET
TAN WIRE
W/O OPTION W/ OPTION
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, w/ led headlamps (2 of 2) -> LEFT FRONT FOG LAMP OPTION CONNECTOR
