Tire pressure monitoring circuit for Nissan Quest IV (2010-2024)

BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-H PNK CAN-L WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 10 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK L GRY WIRE HOT AT ALL TIMES LT GRN WIRE ORG/ WIRE PNK WIRE RECEIVER COMM RECEIVER/SENS GND RED WIRE REMOTE KEYLESS ENTRY RECEIVER (TIRE PRESSURE RECEIVER) RIGHT END OF DASH) SIG TIRE PRESSURE IND, BUZZER TIRE PRESSURE SENSORS YEL WIRE
