Nissan Quest IV (2010-2024) sow sw ind Wiring diagram
This page shows the only wiring diagram for the component.sow sw ind, which is found in the car Nissan Quest IV (2010-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sow sw ind (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BSW COMM-H
BSW COMM-L
BSW CONTROL MODULE (BOTTOM CENTER OF DASH)
BSW IND
BSW SWITCH
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER SIDE DOOR MIRROR
FUSE 45
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY ENERGIZED
IGN
ILL
IND
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT "C" PILLAR)
LEFT BSW INDICATOR
LEFT SIDE RADAR
ORG/ WIRE
PASSENGER SIDE DOOR MIRROR
PNK WIRE
PPL
RED WIRE
RIGHT BSW INDICATOR
RIGHT END OF DASH)
RIGHT SIDE RADAR
SHIELD
SOW SW
SOW SW IND
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Blind spot monitoring circuit -> SOW SW IND
