Nissan Quest IV (2010-2024) right front curtain air bag module Wiring diagram
This page shows the only wiring diagram for the component.right front curtain air bag module, which is found in the car Nissan Quest IV (2010-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front curtain air bag module (1 of 1)
AIR BAG
BCM
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
CRASH ZONE SENSOR
DRIVER AIR BAG MODULE
GRN WIRE
LEFT FRONT DOOR SATELLITE SENSOR
LEFT SEAT BELT PRE-TENSIONER
LT GRN WIRE
NCA WIRE
PASSENGER AIR BAG MODULE
PASSENGER AIR BAG OFF INDICATOR
PNK WIRE
PPL
RED WIRE
RIGHT FRONT CURTAIN AIR BAG MODULE
RIGHT FRONT DOOR SATELLITE SENSOR
RIGHT FRONT SATELLITE SENSOR
RIGHT REAR CURTAIN AIR BAG MODULE
RIGHT REAR SATELLITE SENSOR
RIGHT SEAT BELT PRE-TENSIONER
RIGHT SIDE AIR BAG MODULE
SHIELD
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> RIGHT FRONT CURTAIN AIR BAG MODULE
