Nissan Quest IV (2010-2024) rh buckle sw in Wiring diagram
This page shows the only wiring diagram for the component.rh buckle sw in, which is found in the car Nissan Quest IV (2010-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rh buckle sw in (1 of 1)
AIR BAG DIAGNOSIS SENSOR UNIT
AIR BAG IND
AIR BAG W/L
BLK WIRE
BLU WIRE
BLU/PNK WIRE
BRN WIRE
CAN-H PNK CAN-L WIRE
COMBINATION METER
COMMUNICATION
COMPUTER DATA LINES SYSTEM
CUT OFF TELLTALE
DEPLOYMENT INFORMATION OUT
DRIVER SIDE FRONT SEAT
DRIVER SIDE SEAT BELT BUCKLE SWITCH
ECZS (-)
FR CLH (-)
FR CRH (-)
FUSE 2
FUSE 4
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT W/ IGNITION RELAY ENERGIZED
IGN
K LINE
LEFT "C" PILLAR)
LEFT FRONT CURTAIN AIR BAG MODULE
LEFT FRONT SATELLITE SENSOR
LEFT REAR CURTAIN AIR BAG MODULE
LEFT REAR SATELLITE SENSOR
LEFT SIDE AIR BAG MODULE
LH BUCKLE SW IN PPL SLH (+)
LT BLU WIRE
LT GRN WIRE
OCCUPANT DETECTION SYSTEM CONTROL UNIT
ODS IN
ORG/ WIRE
PASS SEAT BELT WAR SIG
PASSENGER SIDE FRONT SEAT
PASSENGER SIDE SEAT BELT BUCKLE SWITCH
PLH (-)
PNK PLH (+) WIRE
PNK WIRE
PPL
PRH (+) PNK PRH (-) WIRE
RED WIRE
RH BUCKLE SW IN
RR CLH (-)
RR CRH (-)
SATELLITE LH (+)
SATELLITE LH (-) SHIELD GND
SATELLITE RH(+)
SATELLITE RH(-) SHIELD GND
SEAT BELT W/L
SENS LH (-)
SENS RH(-)
SHIELD
SLH (-)
SRH (-)
TAN WIRE
W/ MEMORY W/O MEMORY
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> RH BUCKLE SW IN
