Nissan Quest IV (2010-2024) front side sliding door open/ close switch Wiring diagram
This page shows the only wiring diagram for the component.front side sliding door open/ close switch, which is found in the car Nissan Quest IV (2010-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front side sliding door open/ close switch (1 of 1)
A/C AMPLIFIER
A/C AUTO AMPLIFIER
AUDIO UNIT
AUTOMATIC A/C
AUTOMATIC BACK DOOR SWITCH
AUTOMATIC DOOR MAIN SWITCH
BATTERY TERMINAL W/ FUSIBLE LINK
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BSW SWITCH
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR
DIODE
DOOR MIRROR REMOTE CONTROL SWITCH
DRIVER SIDE FOOT LAMP
DRIVER SIDE HEATED SEAT SWITCH
FRONT SIDE SLIDING DOOR OPEN/ CLOSE SWITCH
FUSE 50
FUSE 51
FUSE 53
FUSE BLOCK (J/B)
FUSIBLE LINK C
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
ILLUMINATION CONTROL SWITCH
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
MANUAL A/C
METER CONTROL SWITCH
PASSENGER SIDE FOOT LAMP
PASSENGER SIDE HEATED SEAT SWITCH
PNK (OR WIRE
PNK PNK (OR WIRE
PNK WIRE
PPL
PUSH BUTTON IGNITION SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
TAIL LAMP RELAY
VDC OFF SWITCH
W/ NAVIGATION
W/ REAR ENTERTAINMENT
W/ REAR VIEW MONITOR W/O REAR VIEW MONITOR W/ NAVIGATION W/O NAVIGATION
W/O REAR ENTERTAINMENT
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> FRONT SIDE SLIDING DOOR OPEN/ CLOSE SWITCH
