Nissan Quest IV (2010-2024) enter sw Wiring diagram
This page shows the only wiring diagram for the component.enter sw, which is found in the car Nissan Quest IV (2010-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram enter sw (1 of 1)
A/C AUTO AMPLIFIER
A/C REC SIG
AIR CONDITIONING SYSTEM
ALTERNATOR SIG
AMBIENT SENSOR
AMBIENT SENSOR GND
AUTO ANTI-DAZZLING INSIDE MIRROR (COMPASS)
BLK WIRE
BLK/PNK WIRE
BLU WIRE
BRAKE FLUID LVL SW
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
COOLANT TEMP SIG
ENTER SW
FRONT SUNROOF MOTOR ASSEMBLY
FUEL LEVEL SENS GND
FUEL LEVEL SENSOR
FUSE 3
FUSE 4
FUSE 6
FUSE BLOCK (J/B)
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
IGN
ILLUMINATION CONTROL
ILLUMINATION SW SIG(+)
ILLUMINATION SW SIG(-) AIR BAG
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
LT GRN WIRE
METER CTRL SW GND
O/D CTRL SW SIG
ORG/ WIRE
PARKING BRAKE SW
PNK WIRE
PPL
REAR SUNROOF MOTOR ASSEMBLY
RED WIRE
RIGHT END OF DASH)
SEAT BELT BUCKLE SW
SEAT BELT WARN SIG
SECURITY SIG
SELECT SW
SIG SPD
SPD SIG
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
TEL ADAPTER UNIT
TRANSMISSIONS SYSTEM
TRIP RESET SW
VEH SPD (8-PULSE)
WARNING SYSTEMS SUPPLEMENTAL RESTRAINTS SYSTEM
WASHER LVL SW
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> ENTER SW
