Nissan Quest IV (2010-2024) driver side seat belt buckle switch, lumbar support switch, Wiring diagram
This page shows the only wiring diagram for the component.driver side seat belt buckle switch, lumbar support switch,, which is found in the car Nissan Quest IV (2010-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side seat belt buckle switch, lumbar support switch, (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ALTERNATOR
BCM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BRN/YEL WIRE
COMPRESSOR, COOLING FAN RELAY 2
DRIVER SIDE SEAT BELT BUCKLE SWITCH, LUMBAR SUPPORT SWITCH,
ENGINE CONTROL MODULE (ECM)
FRONT POWER WINDOW SWITCH
IGNITION COILS 1, 2, 3, 4, 5, 6 (W/ POWER TRANSISTOR), CONDENSER
INSIDE KEY ANTENNA (LUGGAGE ROOM) SHIELD, PASSENGER SIDE SEAT CUSHION HEATER
LEFT "C" PILLAR)
LT GRN WIRE
PASSENGER SIDE
POWER STEERING CONTROL MODULE
W/ HEATED SEATS
W/O MEMORY
Go to component -> Ground distribution circuit -> DRIVER SIDE SEAT BELT BUCKLE SWITCH, LUMBAR SUPPORT SWITCH,
